Core Thickness: 3/4″ thick MDF

Standard Panel Size: 48″ x 96″

Pattern Depth: 3/8″

Square Foot Weight: 2.41 lbs

Pattern Orientation: None

Core Options: Premium MDF with Class C Fire Rating, Class A Fire Rated / FF MDF or Exterior Grade MDF

Pattern Repeat: Horizontal and Vertical. The Carta pattern can also be force matched.

Soelberg is not responsible for inconsistencies in pattern continuation if panel configuration is not provided by the customer. Because we tailor the pattern to your project dimensions, in some cases, when adding additional panels to a project, pattern continuation is not achievable.


The Carta pattern consists of sharp beveled angles to create a beautifully random and almost scale-like texture. Whether used in small spaces for a statment-making desk front or for walls with continued pattern repetition, Carta makes a memorable interior.

Installation Methods:

Z-clip hardware, point support, industrial adhesive, aluminum channeling and other various millwork applications. Direct screw can be used if ordered unfinished. Because Soelberg Industries does not provide installation services, we recommend that you work directly with a professional contractor or millworker.


Standard 4′ x 8′ panel with horizontal and vertical pattern repeat
